UNITRON® Inspex HD 1080p Digital Inspection System

Unitron Logo

Authorized Distributor

UNITRON Inspex HD 1080p Monitor

UNITRON's unique Inspex HD 1080p Digital Inspection System has an modular, ergonomic, versatile design providing great choices in mounting options. The system is packed with lots of great features including an easy to use on-screen menu for  many of the camera features, accessible controls, a high definition camera system with superior image quality and removable USB storage for storing images directly to your USB storage device via the built-in USB port. With the optional external controller, added features include use of three memory pre-sets, infrared mode, real time dimensioning grids, exposure and focus control. The Inspex HD 1080p is hard to beat for production areas, repair and rework, quality control and failure diagnosis in fields like automotive, aviation, electronics, engineering.  Monitor not included.

Request Quote Product Brochure

Specifications

Camera resolution Full HD 1080p (1920 x 1080)
Connections HDMI out, USB for image capture
Focus Auto / Manual
Illumination Adjustable LED illumination
Dimensions Table Stand: 16"(d) x 9.5"(w) x 16.5"(h) / 410mm(d) x 240mm(w) x 419mm(h)
Response time 5ms
Weight Table Stand: 5.51lbs. (2.5kg)
Power Supply 100/240v, 50/60Hz
Power Consumption 8 watts
Recommended Monitor 16:9 DVI & HDMI, Response time: 5ms, Signal: Full HD 1080p (Monitor not included)
Standard Functions Auto/manual focus, image capture, brightness adjustment, magnification adjustment, snapshot, overview, high contrast mode, height adjustable
Optional Accessories LED ring lights, fiber optic illuminators, Auxiliary objectives, Polarizers, Stands

Inspex HD 1080p Field of View & Depth of Field (With 24" monitor)

4x Lens (Diopter) 5x Lens (Diopter) 10x Lens (Diopter)
Magnification Level FOV
X AXIS (MM)
FOV
Y AXIS (MM)
Depth of Field (mm) FOV
X AXIS (MM)
FOV
Y AXIS (MM)
Depth of Field (mm) FOV X AXIS (MM) FOV
Y AXIS (MM)
Depth of Field (mm)
1.8 280 164 100 - - - - - -
2.5 200 116 45 208 122 50 - - -
3 168 98 37 168 98 32 - - -
5 102 59 21 102 59 21 - - -
7 74 42 15 74 42 11 - - -
10 52 29 10 52 29 - - -
15 35 19.5 5 35 19.5 4 - - -
20 25.5 14.2 2.8 25.5 14.2 3 - - -
30 16 9 1.8 17 9.5 2 17 9.5 2
40 11.8 6.6 1.1 12.7 7.1 1.5 12.7 7.1 1
50 10.4 5.8 0.7 10 6.1 1 10 6.1 0.5
70 7.1 4 - 6.7 3.8 - 7.1 4 -
100 - - - 4.6 2.6 - 4.9 2.6 -
150 - - - - - - 3 1.7 -
200 - - - - - - 2.7 1.2 -

Gray areas indicate results at digital zoom

Lens diopter: The optical power of the lens in diopters.

Magnification: The magnification level for the associated lens on a 24" monitor.

Field of View: The viewing distance (in mm) in both horizontal (X) and vertical (Y) axes at minimum and maximum magnification levels.

Depth of Field: The focus depth (in mm) at minimum and 10x magnification levels.
