UNITRON Z730 ZOOM SERIES

Unitron Logo

Authorized Distributor

UNITRON Z730

UNITRON's Z730 zoom stereo microscope offers a large field of view with high focus depth, helping to reduce sample handling times and increase efficiency. This model is ideal for industrial inspection, assembly, quality control, OEM integration, or research and education applications. Available with choice of binocular or trinocular viewing head.

Request Quote Product Brochure

Specifications

VIEWING BODY
Optical system Twin zooming objectives
Viewing Bodies Binocular or Trinocular with 50/50 light split, inclined 45° for binocular and trinocular models, binocular viewing head also available in 60° viewing angle.
ESD Protection Viewing body is made from anti-electrostatic materials
Anti-Mold Anti-mold and airtight design
Magnification 0.7x to 3.0x (7x to 30x with 10x eyepieces). Zoom Ratio: 4.3:1
Working Distance 97mm (3.82 inches)
Interpupillary Distance Adjustment 52-75mm
Camera Adaptability 0.5x c-mount adapter
Eyepieces WF 10x/20mm with reticle holder (reticle size: 26.5mm), WF 15x/16mm with reticle holder (reticle size: 20mm), WF 20x/12.5mm (optional reticle holder available, reticle size: 16.5mm)
Auxiliary Objectives 0.5x (180mm working distance), 0.63x (140mm working distance), 0.75x (120mm working distance) and 2.0x (30mm working distance)
STANDS
Plain Focusing Stand 76mm focus mount diameter, 100mm focusing stroke, 240mm(l) x 290mm(d) x 318mm(h), 125mm black & white stage plate
LED Reflected/Transmitted Illuminated Stand 76mm focus mount diameter, 100mm focusing stroke, 184mm(l) x 260mm(d) x 267mm(h), 95mm clear glass stage plate and black & white stage plate. Variable transmitted and reflected LED illumination; average LED life expectancy-50,000 hours. Color temperature: 6500° - 70000° Kelvin.
Diascopic Stand with Transmitted Illumination Attachment 76mm focus mount diameter, 100mm focusing stroke, 255mm(l) x 310mm(d) x 382mm(h), 280mm clear glass stage plate, tiltable mirror provides direct and oblique illumination with either 6v20w halogen illuminator, 150w fiber optic or LED illuminators.
Pole Stand 76mm focus mount diameter, 305mm pole height, 193mm focusing stroke, 240mm(l) x 290mm(d) x 318mm(h), 125mm black & white stage plate
Boom Stand Base dimensions 254mm x 254mm (10" x 10"), vertical post-365mm, horizontal post-518mm. Physical weight 34lbs
Ball Bearing Boom Stand Base dimensions 254mm x 254mm (10" x 10"), vertical post-394mm, horizontal post-585mm. Physical weight 42lbs
Articulating/Flex Arm Stand Flexible arm stand, lockable 14-1/2" vertical motion range, 3' scannable range, horizontal/vertical clamp mount, table mount, or wall mount
ADDITIONAL INFO
Accessories Dust cover and instruction manual.
Warranty 5 year limited warranty for parts, labor, and electronic components.

Optical Data

Auxiliary Objective Working Distance (mm) EYEPIECE
WF10X/22 WF15X/16 WF20X/12.5
Total Magnification Visual Field (mm) Total Magnification Visual Field (mm) Total Magnification Visual Field (mm)
97 7-30X 25.7-6 10.5-45X 20.0-4.7 14-60X 15.7-3.7
0.5X 180 3.5-15X 51.4-12 5.2-22.5X 40.0-9.4X 7-30X 31.4-7.4
0.63X 140 4.4-18.9X 43.9-10.6 6.6-28.3X 31.7-7.4 8.8-37.8X 24.9-5.8
2X 30 14-60X 12.8-3 21-90X 10.0-2.3 28-120X 7.9-1.8

Optional Accessories

  • Digital & HD cameras with image analysis software.
  • Light Sources: LED and fluorescent ring lights, fiber optic illuminators
  • Auxiliary objectives: 0.3x, 0.63x, 2.0x
  • Eyepieces: 15x focusing, 20x focusing
  • Reticles and stage micrometers
